Urban Drainage & Flood Prevention Solution

Based on the topology of "Plant - Station - Pipeline Network - Household" and online monitoring data, this solution can comprehensively supervise urban drainage and flood prevention facilities, waterlogging spots, and drainage pipeline (channels) while integrated application of GIS, BIM, hydraulic model, etc., to provide real-time supervision, operation and maintenance coordination, traceability analysis, intelligent scheduling, preview and early warning. Help customers improve urban drainage facilities' management and scheduling capabilities to reduce the urban waterlogging risk.

Emergency response time: 2 minutes
Manual intervention frequency: 0.3 times/hour
Tracing Pollution in Seconds
Rainfall Prevention Capability: 75 mm per hour (Rainfall Intensity)

Technology Empowers Flood Prevention & Drainage in Shenzhen

Through the construction of the "Sky-ground-water" ubiquitous supervision system, all business-related data, such as water quality and water level, of the entire drainage process from the municipal rainwater pipe network to the terminal river facilities and equipment are mastered in real-time.

Managing 9046 Drainage Communities

Managing: over 20000 km drainage pipeline network

Managing: 850000 drainage inspection Wells

Managing: nearly 600000 Rainwater outfall

Key Features of the Solution

Unified management of water assets

Based on GIS, the drainage supervision information of drainage households, community pipe network, municipal pipe network, pumping station, water purification plant and drainage outlet is comprehensively displayed, and systematically analyzes data collected by video surveillance and intelligent terminals.

Intelligent diagnose various pipeline problems & efficient maintenance

Relying on GIS and BIM system, the drainage pipe diagnosis database is built to help intelligently identify problems such as mixed connection, reverse slope, and unconnected in drainage pipe networks. It can explore the pipe network for 20,000 kilometers in 5 minutes.

Urban waterlogging simulation & early warning

Utilizes urban hydrological and drainage simulation system to simulate urban waterlogging in different rainfall levels and provides decision support for drainage system scheduling

Flood prevention and emergency linkage scheduling, intelligent preplan database

Through the plant network linkage, remote pre-adjust water level, coordination of various departments linkage emergency command, accurate scheduling of personnel, vehicles and materials. At the same time, the scheduling preplan database is established and optimized by the intelligent scheduling model.

Pollution Tracing

Comprehensive analysis of upstream and downstream connectivity, online-monitor data and periodic fluctuations of indicators, narrowing the scope of pollution sources until identified.

Smart Plant/Station Technical & Construction Standard from Shenzhen Water Technologies Co., Ltd

Nearly 10 years of plant digitization upgrade and 25 years automatic control experience, we have deeply analyzed the Smart Plant/station Solution "1.0-2.0-3.0" Construction Plan that can be evaluated and dismantled, and the planning has avoided repeated cost input to ensure the practical implementation.
